200ZYT系列 |
|
|
|
有刷直流電機
通用規范
| Voltage Range |
12 & 24v dc (240v also available) |
| Power Output Range |
150-600 W |
| Speed Range |
0-6000 RPM |
| Operational Temperature |
–20℃～+40℃ |
| Insulation Class |
F(contact us for class B) |
| Housing Type |
Closed(ventilated also available） | |
規格介紹
規格參數
| Part Number |
Voltage |
No load Current |
No load Speed |
Torque |
Rated Current |
Rated Speed |
Rated Power |
Length |
| Units |
V |
A |
RPM |
Nm |
A |
RPM |
W |
mm |
| 200ZYT001 |
115 |
5 |
3750 |
2.2 |
15 |
3200 |
1100 |
224 |
| 200ZYT002 |
230 |
3 |
3750 |
2.2 |
8 |
3200 |
1100 |
224 |
| 200ZYT003 |
24 |
5 |
3750 |
1.7 |
38 |
3200 |
570 |
224 |
| 200ZYT005 |
48 |
3.5 |
3750 |
1.7 |
27 |
3200 |
570 |
224 | |
|
|
|
