交流電機(YY120系列) |
|
|
|
交流電機
通用規范
|
Voltage Range |
115 & 230v AC |
|
Power Output Range |
150w-300W |
|
Speed Range |
1000-3000RPM |
|
Operational Temperature |
–20℃～+40℃ |
|
Insulation Class |
F(consult us for class B) | |
規格介紹
規格參數
|
Part Number |
Voltage |
No load Current |
No load Speed |
Torque |
Rated Current |
Rated Speed |
Rated Power |
Length |
|
Units |
V |
A |
RPM |
Nm |
A |
RPM |
W |
mm |
|
YY120-2 |
230 |
0.5 |
2920 |
0.57 |
1.3 |
2750 |
120 |
176.5 |
|
YY120-3 |
115 |
0.7 |
3500 |
0.35 |
2.5 |
3350 |
120 |
176.5 |
|
|
|
|
