產品中心 |
|
|
ZJD8025系列 |
|
|
|
齒輪電機
通用規范
|
Gearbox Housing |
Ruggedised die-cast Aluminium |
|
Worm Gear Material |
Brone,steel or glass-filled plastic |
|
Lubrication |
Grease lubricated & sealedfor life |
|
Gearbox Output Bearing Type |
High quality ball bearing |
|
Insulation Class |
F(contact us for classB) |
|
Brush Type |
Integral or removable |
|
Ambient Operating Temperature |
-20℃ to +40℃ | |
規格介紹
規格參數
|
Part Number |
Voltage |
Ratlo |
No load Speed |
Torque |
Rated Current |
Rated Speed |
Rated Power |
Length |
|
Units |
V |
/ |
RPM |
Nm |
A |
RPM |
W |
mm |
|
ZJD8025A |
12 |
60:1 |
50 |
37 |
50 |
40 |
600 |
240.5 |
|
ZJD8025B |
12 |
90:1 |
60 |
50 |
75 |
48 |
900.0 |
270.5 | |
|
|
|
